Steel Flat Bar

DETAILS AND PARAMETERS

TOLERANCES

TECHNICAL SHEET

Hot Rolled Steel Flat, is widely used for all general fabrication and repairs in industrial maintenance, agricultural implements, transportation equipment, etc. HR A569 Steel Flat is stripped from coil and A36 is rolled as bars. Metals Depot stocks hundreds of sizes of steel flat that you can buy online in ready to ship precut or mill lengths or you can order just what you need custom Cut to Size in small or large quantity at wholesale prices.

SPECIFICATIONS:

ASTM A569 (1/16" - 3/16"), A36 (1/4" & over)

FINISH:

A569 is smooth, A36 is slightly grainy, mill finish

CHARACTERISTICS:

Welding = Excellent
Machining / Grinding = Good
Bending / Forming = Good
Wear Resistance = Fair
Corrosion Resistance = Poor

A36 MECHANICAL PROPERTIES:

Yield Point = 36,000 psi
Tensile Strength = 48-80,000 psi
Elongation = 23% in 2"
Brinell Hardness = 133; Melting Point = 2600F
*Data provided for reference only

AVAILABLE STOCK SIZES:

2ft, 4ft. 6ft, 8ft, 10ft, 20ft, or Cut to Size
Stock lengths may vary +/- 1/4"

HOW TO MEASURE:

Thickness (A) X Width (B) X Length
*Mill Tolerances Apply

Flats

			Width (mm)			Thickness (mm)
Cod. Prod	Producto	Calidad	Mín	Nom	Máx	Mín	Nom	Máx
5500127	PERFIL HEMBRA 1"X1/8"X6M	Legítimo	25.00	25.40	25.80	3.00	3.18	3.35
5500129	PERFIL HEMBRA 1"X3/16"X6M	Legítimo	25.00	25.40	25.80	4.58	4.76	4.94
5500130	PERFIL HEMBRA 1"X1/4"X6M	Legítimo	25.00	25.40	25.80	6.15	6.35	6.55
5500164	PERFIL HEMBRA 1/2"X1/8"X6M	Legítimo	12.30	12.70	13.10	3.00	3.18	3.35
5500165	PERFIL HEMBRA 1/2"X3/16"X6M	Legítimo	12.30	12.70	13.10	4.58	4.76	4.94
5500166	PERFIL HEMBRA 1/2"X1/4"X6M	Legítimo	12.30	12.70	13.10	6.15	6.35	6.55
5500167	PERFIL HEMBRA 5/8"X1/8"X6M	Legítimo	15.48	15.88	16.27	3.00	3.18	3.35
5500168	PERFIL HEMBRA 5/8"X3/16"X6M	Legítimo	15.48	15.88	16.27	4.58	4.76	4.94
5500169	PERFIL HEMBRA 5/8"X1/4"X6M	Legítimo	15.48	15.88	16.27	6.15	6.35	6.55
5500170	PERFIL HEMBRA 3/4"X1/8"X6M	Legítimo	18.65	19.05	19.45	3.00	3.18	3.35
5500171	PERFIL HEMBRA 3/4"X3/16"X6M	Legítimo	18.65	19.05	19.45	4.58	4.76	4.94
5500172	PERFIL HEMBRA 3/4"X1/4"X6M	Legítimo	18.65	19.05	19.45	6.15	6.35	6.55
5500173	PERFIL HEMBRA 1"X3/8"X6M	Legítimo	25.00	25.40	25.80	9.32	9.53	9.73
5500128	PERFIL HEMBRA 1"X3/16X6M R	Milimétrico	24.60	25.40	26.20	3.90	4.00	4.10
5500131	PERFIL HEMBRA 1 1/4"X1/8"X6M	Legítimo	30.96	31.75	32.54	3.00	3.18	3.35
5500132	PERFIL HEMBRA 1 1/4"X3/16"X6M	Legítimo	30.96	31.75	32.54	4.58	4.76	4.94
5500133	PERFIL HEMBRA 1 1/4"X1/4"X6M	Legítimo	30.96	31.75	32.54	6.05	6.35	6.65
5500134	PERFIL HEMBRA 1 1/2"X1/8"X6M	Legítimo	37.31	38.10	38.89	3.00	3.18	3.35
5500135	PERFIL HEMBRA 1 1/2"X3/16"X6M	Legítimo	37.31	38.10	38.89	4.58	4.76	4.94
5500136	PERFIL HEMBRA 1 1/2"X1/4"X6M	Legítimo	87.31	88.90	90.49	5.97	6.35	6.73
5500137	PERFIL HEMBRA 2"X1/8"X6M	Legítimo	50.01	50.80	51.59	3.00	3.18	3.35
5500138	PERFIL HEMBRA 2"X3/16"X6M	Legítimo	50.01	50.80	51.59	4.58	4.76	4.94
5500139	PERFIL HEMBRA 2"X1/4"X6M	Legítimo	50.01	50.80	51.59	6.05	6.35	6.65
5500174	PERFIL HEMBRA 1 1/4"X3/8"X6M	Legítimo	30.96	31.75	32.54	9.22	9.53	9.83
5500175	PERFIL HEMBRA 1 1/4"X1/2"X6M	Legítimo	30.96	31.75	32.54	12.40	12.70	13.00
5500176	PERFIL HEMBRA 1 1/2"X3/8"X6M	Legítimo	37.31	38.10	38.89	9.22	9.53	9.83
5500177	PERFIL HEMBRA 1 1/2"X1/2"X6M	Legítimo	37.31	38.10	38.89	12.40	12.70	13.00
5500178	PERFIL HEMBRA 2"X3/8"X6M	Legítimo	50.01	50.80	51.59	9.22	9.53	9.83
5500179	PERFIL HEMBRA 2"X1/2"X6M	Legítimo	50.01	50.80	51.59	12.40	12.70	13.00
5500180	PERFIL HEMBRA 2 1/2"X1/4"X6M	Legítimo	61.91	63.50	65.09	5.97	6.35	6.73
5500181	PERFIL HEMBRA 2 1/2"X3/8"X6M	Legítimo	61.91	63.50	65.09	9.14	9.53	9.91
5500182	PERFIL HEMBRA 2 1/2"X1/2"X6M	Legítimo	61.91	63.50	65.09	12.32	12.70	13.08
5500183	PERFIL HEMBRA 3"X1/8"X6M	Legítimo	74.61	76.20	77.79	2.97	3.18	3.38
5500184	PERFIL HEMBRA 3"X3/16"X6M	Legítimo	74.61	76.20	77.79	4.56	4.76	4.97
5500185	PERFIL HEMBRA 3"X1/4"X6M	Legítimo	74.61	76.20	77.79	5.97	6.35	6.73
5500186	PERFIL HEMBRA 3"X3/8"X6M	Legítimo	74.61	76.20	77.79	9.14	9.53	9.91
5500187	PERFIL HEMBRA 3"X1/2"X6M	Legítimo	74.61	76.20	77.79	12.32	12.70	13.08
5500188	PERFIL HEMBRA 4"X3/16"X6M	Legítimo	100.01	101.60	103.19	4.56	4.76	4.97
5500189	PERFIL HEMBRA 4"X1/4"X6M	Legítimo	100.01	101.60	103.19	5.97	6.35	6.73
5500190	PERFIL HEMBRA 4"X3/8"X6M	Legítimo	100.01	101.60	103.19	9.14	9.53	9.91
5500191	PERFIL HEMBRA 4"X1/2"X6M	Legítimo	100.01	101.60	103.19	12.32	12.70	13.08
5500192	PERFIL HEMBRA 5"X1/4"X6M	Legítimo	124.62	127.00	129.38	5.97	6.35	6.73
5500193	PERFIL HEMBRA 6"X3/16"X6M	Legítimo	150.02	152.40	154.78	4.53	4.76	4.99
5500194	PERFIL HEMBRA 6"X1/4"X6M	Legítimo	150.02	152.40	154.78	5.97	6.35	6.73
5500195	PERFIL HEMBRA 6"X3/8"X6M	Legítimo	150.02	152.40	154.78	9.14	9.53	9.91
5500196	PERFIL HEMBRA 6"X1/2"X6M	Legítimo	150.02	152.40	154.78	12.32	12.70	13.08

CHEMICAL COMPOSITION
Element	Percentage
C	0.26
Cu	0.2
Fe	99
Mn	0.75
P	0.04 max
S	0.05 max

MECHANICAL INFORMATION
	Imperial	Metric
Density	0.282 lb/in3	7.8 g/cc
Ultimate Tensile Strength	58,000psi	400 MPa
Yield Tensile Strength	47,700psi	315 MPa
Shear Strength	43,500psi	300 MPa
Melting Point	2,590 - 2,670°F	1,420 - 1,460°C
