Angle Steel
A36 Steel Angle is one of the most popular hot rolled, low carbon steel shapes used in manufacturing, fabrication, and repair projects. From trailers to truck beds, farm implements to construction equipment, steel angle has thousands of uses and applications. Its 90 degree angle shape adds strength and rigidity to any project for a lower price compared to other shapes and types of metal. It is easy to weld, cut, form and machine. Metals Depot stocks hundreds of sizes of steel angle that you can buy online in ready to ship precut or mill lengths or you can order just what you need custom Cut to Size in small or large quantity at wholesale prices.
|
TOLERANCES OF A36 STEEL ANGLE (+/-) |
||||||
|
Angle Size |
Length of Leg |
Thickness |
Straightness in 10 feet |
Lengths +/- |
Out of Square |
|
|
Custom Cut |
Standard |
|||||
|
1/2 to 1 |
1/32 |
.010 |
1/4 |
1/16 |
1/4 |
1.5 degree |
|
1-1/8 to 2 |
3/64 |
.010 |
1/4 |
1/16 |
1/4 |
3 degree |
|
2-1/4 to 3 |
1/16 |
.015 |
1/4 |
1/16 |
1/4 |
4.5 degree |
|
3-1/4 to 4 |
1/8 |
.015 |
1/4 |
1/16 |
1/4 |
6 degree |
|
4-1/2 to 6 |
1/8 |
.015 |
1/4 |
1/8 |
1/2 |
9 degree |
|
Over 6 |
3/16 |
.015 |
1/4 |
1/8 |
1/2 |
12 degree |
|
CHEMICAL COMPOSITION |
|
|
Element |
Percentage |
|
C |
0.26 |
|
Cu |
0.2 |
|
Fe |
99 |
|
Mn |
0.75 |
|
P |
0.04 max |
|
S |
0.05 max |
|
MECHANICAL INFORMATION |
||
|
|
Imperial |
Metric |
|
Density |
0.282 lb/in3 |
7.8 g/cc |
|
Ultimate Tensile Strength |
58,000psi |
400 MPa |
|
Yield Tensile Strength |
47,700psi |
315 MPa |
|
Shear Strength |
43,500psi |
300 MPa |
|
Melting Point |
2,590 - 2,670°F |
1,420 - 1,460°C |
|
Hardness Brinell |
140 |
|
Production Method |
Hot Rolled |
